22.2V 17000mAh Drone Battery with 240 Cycles and 85A Peak Discharge

Brand Name : OiD

Model Number : OiD9270170-17000-5C-22.2

Certification : Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Place of Origin : China

MOQ : 100pcs

Price : $0.5 ~ $100.0 / pcs

Delivery Time : 3 ~ 7 days for storage

Payment Terms : TT,L/C,Western Union

Name : Drone Battery

Battery Type : 22.2V 17000mAh Rechargeable

ODM : Free custom design for packs

Cycle Life : 240+ cycles

Charging/ Discharging : 17A/51A

Operating Temperature : -20°C~60°C

Compatibility : XT90S-F (discharge), G-Tech-7P (charge)

Weight/ size : 1600g/186±5mm (L) x 71.5±1.5mm (W) x 55±2mm (H)

Contact Now

OiD9270170-17000-5C-22.2 Drone Battery 22.2V 17000mAh 85A Peak Discharge 240 Cycles

Product Name

OiD9270170-17000-5C-22.2 Drone Battery

Advantages

High energy density for extended flight endurance
Optimized 5C discharge rate for stable power output
Lightweight design with robust cycle life

Specifications

Parameter	Value
Nominal Voltage	22.2V (6S1P)
Nominal Capacity	17000mAh (0.2C discharge)
Minimum Capacity	16600mAh
Internal Impedance	12±3.5mΩ (1kHz AC method)
Charging
Standard Charge Current	3.4A (0.2C)
Fast Charge Current	17A (1C)
Max Charge Voltage	25.2V
Discharging
Standard Discharge Current	3.4A (0.2C)
Max Continuous Discharge	51A (3C)
Peak Discharge Current	85A (5C, ≤3 seconds)
Discharge Cut-Off Voltage	17.1V (0.2C) / 18.0V (≥0.5C)
Dimensions	186±5mm (L) x 71.5±1.5mm (W) x 55±2mm (H)
Weight	1600±100g
Connectors	XT90S-F (discharge), G-Tech-7P (charge)

Cycle Life

Test Condition	Cycles
0.5C CC/CV charge to 25.2V, 51A discharge to 18.0V (Capacity ≥80% of initial)	240

Operating Temperature Range

Operation	Temperature Range	Current Limit
Charging	10°C to 45°C	≤17A (1C, 15°C–45°C)
Discharging	-20°C to 60°C	≤51A (15°C–45°C recommended)
Storage	-20°C to 35°C	N/A

Certifications

Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Key Features

Fast Charging: Supports 1C charging (1.5 hours).
High Efficiency: ≥98% discharge efficiency at 20°C.
Durable: Aluminum foil packaging with impact-resistant design.

Applications

Commercial drones
Aerial photography platforms
Industrial inspection UAVs

Usage Warnings & Precautions

Voltage Limits: Do not exceed 25.2V (charge) or discharge below 17.1V (0.2C).
Temperature: Avoid charging below 10°C or discharging above 60°C.
Safety: Never disassemble or expose to water/fire.

Storage Guidelines

Short-term: Store at 22.5–23.4V (25±3°C, ≤75% RH).
Long-term: Maintain 22.5–23.4V; activate every 3 months (0.2C cycle).

Warranty & Disclaimer

12-month warranty from shipment date.
Void if misused or stored improperly.
